How to Grow XFS Filesystem in RHEL 7

XFS is the default filesystem in the Red hat Enterprise Linux 7 (RHEL 7) with many advantages and in this tutorial you will learn to how to extend or grow XFS filesystem online in RHEL 7 without causing any damage. It is somewhat similar to the EXT4 filesystem only there is a command difference.

There are many scenarios and situations where you have to extend your filesystem. This can be due to exhausting space in the filesystem or it’s going to be exhausted, or space is needed for copying new files and directories or anything like that. So, the task of a system administrator is to meet that request.



How to Grow XFS Filesystem in RHEL 7 or CentOS



For this tutorial, we already assume that you already have created and mounted your XFS filesystem on your server and you are ready to extend it. And if you haven’t created till now follow this tutorial on how to create an XFS filesystem on RHEL 7.



Steps to Extend / Grow XFS Filesystem in RHEL 7 or CentOS



1. Login to your RHEL 7 server or workstation as root. You can also login as a normal user and then sudo to root.



2. Check if space is available in the volume group (VG) having that logical volume that you want to grow. If space is not available then you can first add storage to your server and then can use “lvextend” and “xfs_growfs” commands.

In the below example, we have increased only 100mb on “/data/db” filesystem for demonstration. You can see earlier filesystem was 87% utilized, but after increasing, it becomes 72% utilized.




[root@rhel7 data]# df -hP /data/db
Filesystem                     Size  Used Avail Use% Mounted on
/dev/mapper/datavg-databaselv  493M  425M   68M  87% /data/db


[root@rhel7 data]# lvextend -L +100M /dev/mapper/datavg-databaselv
  Extending logical volume databaselv to 596.00 MiB
  Logical volume databaselv successfully resized


[root@rhel7 data]# xfs_growfs /dev/mapper/datavg-databaselv
meta-data=/dev/mapper/datavg-databaselv isize=256    agcount=4, agsize=31744 blks
         =                       sectsz=512   attr=2, projid32bit=1
         =                       crc=0
data     =                       bsize=4096   blocks=126976, imaxpct=25
         =                       sunit=0      swidth=0 blks
naming   =version 2              bsize=4096   ascii-ci=0 ftype=0
log      =internal               bsize=4096   blocks=853, version=2
         =                       sectsz=512   sunit=0 blks, lazy-count=1
realtime =none                   extsz=4096   blocks=0, rtextents=0
data blocks changed from 126976 to 152576



Note: If storage is not available on your server, then check if your server is physical or virtual. If your server is physical ask your storage team to give you the desired size LUN and if the server is virtual then ask your VM team or if you have access then add yourself the VM disk of the desired size or increase the size of the existing disk attached to a virtual server.

If you have added a new disk to a server, please first create a new “PV” and then extend the “VG” and then follow the above steps.

To summarize, commands can be written as below.


pvcreate /dev/sdX
vgextend VG_Name /dev/sdX
lvextend -L +Size LV_name
xfs_growfs LV_name



3. Once your XFS filesystem has been expanded, just verify using “df” command like below.


[root@rhel7 data]# df -hP /data/db
Filesystem                     Size  Used Avail Use% Mounted on
/dev/mapper/datavg-databaselv  593M  425M  168M  72% /data/db
[root@client10 data]#



This is how you can easily grow XFS filesystem online in Red hat Enterprise Linux 7 (RHEL 7) or CentOS 7.


This was a simple beginner tutorial for the growing XFS filesystem on RHEL 7 servers and, if you have a problem in any step, please let us know. If you like this tutorial do not forget to share it with your friends and social groups. If you need any other tutorial, please mail us or comment below. You can also subscribe to our blog for more such articles.
